How do you calculate copper busbar ampacity?

What is the ampacity of a bus bar?

  • As a nod to those who continue to deal with wires, the ampacity chart includes a handy conversion between the square inch area of bus bars and the circular mils of wiring. For example, a 1/16 x 1/2 inch bus bar has an area of 0.0312 inches square, and the equivalent circular area of 39.7 circular mils.

What is the ampacity of a 50x10 copper bar?

  • E.g. for the same cross-section in sq. mm and working temperature, a 100x5 mm bar carries 1.431 Ampere, whereas the same cross-section, with a 50 x 10 mm bar carries 1.129 Amp (cf. ampacity values on page 16, table for solid copper bars, referred to a ΔT 50°C).

What is the emissivity of a busbar?

  • Ampacities of Copper No. 110 Busbars - Ampacities in the table below are for bus bars having an emissivity of 0.4. This was observed on samples exposed for 60 days in an industrial environment, and it is probably identical to that of bus bars in service. Dimensions, In.
