What to look for in an air compressor wiring diagram?
What are the components of an air compressor?
- Suction filter, and other minor components. An Air Compressor has a cylinder head which differs depending upon the type. It may be in-line or even in “V”-shape. If it is in-line, usually the 1st stage and 2nd stage are in a same cylinder head block.
What are the parts of a V-shaped compressor?
- But in a “V”-shaped compressor, the 1st stage and 2nd stage may be entirely different connected by high pressure pipes. The cylinder head consists of pockets for holding the intake/suction and delivery valves. They also have air cooling fins or water jacket for cooling water passage.
What are the parts of a rotary screw compressor?
- 1. Check Valve 2. Compressor Pump 3. Pump Flywheel 4. Air Filter 5. Motor 6. Pressure Switch 7. Gauge 8. Safety Relief Valve A rotary screw is a compressor which utilizes two intermeshing helical rotors to trap a volume of air, then compress it to a higher pressure.
